Programmable supply priority for PV,Battery or Grid
User-adjustable battery charging current suits different types of batteries
Programmable multiple operation modes: Grid-tie,Off-grid and grid-tie with backup
Built-in timer for various mode of on/off operation
Multiple communication for USB,RS232,Modbus and SNMP
Monitoring software for rel-time status display and control
Parallel operation up to 6 units for 10KW
Specification
PHASE
1-phase in/1 phase out
1-phase in/1 phase out
3-phase in/3-phase out
Max. PV INPUT POWER
5000W
6500W
14850W
Rated Output Power
5000W
5500W
10000W
Maximum Charging Power
4800 W
2880 W
9600 W
GRID TIE OPERATION
PV INPUT (DC)
Nominal DC Voltage/Max. DC Voltage
720 VDC/900 VDC
360 VDC/500 VDC
720 VDC/900 VDC
Start-up Voltage/Initial Feeding Voltage
225 VDC/250 VDC
116 VDC/150 VDC
320 VDC/350 VDC
MPP Voltage Range
250 VDC~850 VDC
120 VDC~450 VDC
400 VDC~800 VDC
Number of MPP Trackers/
2/2x10A
2/2x13A
2/2×18.6A
Maximum Input Current
GRID OUTPUT (AC)
Nominal Output Voltage
208/220/230/240 VAC
208/220/230/240 VAC
230 VAC (P-N)/
400 VAC (P-P)
Output Voltage Range
184 -265 VAC*
184 -265 VAC*
184 – 265 VAC* per phase
Nominal Output Current
21A
23.9A
14.5A per phase
Power Factor
＞ 0.99
EFFICIENCY
Maximum Conversion Efficiency (DC/AC)
96%
European Efficiency@Vnominal
95%
OFF GRID OPERATION
AC INPUT
AC start-up Voltage/
120-140 VAC/180 VAC
120-140 VAC/180 VAC
120-140 VAC per phase/
Auto Restart Voltage
180 VAC per phase
Acceptable Input Voltage Range
170-280 VAC
170-280 VAC
170-280 VAC per phase
Max. AC Input Current
21A
40A
40A
PV INPUT (DC)
Max. DC Voltage
900 VDC
500 VDC
900 VDC
MPP Voltage Range
250 VDC~850 VDC
120 VDC~450 VDC
400 VDC~800 VDC
Number of MPP Trackers/Max. Input Current
2/2x10A
2/2x13A
2/2×18.6A
BATTERY Mode Output (AC)
Nominal Output Voltage
202/208/220/230/240 VAC
202/208/220/230/240 VAC
230 VAC (P-N)/400 VAC (P-P)
Output Waveform
Pure Sine Wave
Efficiency (DC to AC)
93%
93%
91%
HYBRID OPERATION
PV INPUT (DC)
Nominal DC Voltage/Max. DC Voltage
720 VDC/900 VDC
360 VDC/500 VDC
720 VDC/ 900 VDC
Start-up Voltage/Initial Feeding Voltage
225 VDC/ 250 VDC
116 VDC/150 VDC
320 VDC/ 350 VDC
MPP Voltage Range
250 VDC~ 850 VDC
120 VDC~450 VDC
400 VDC~800 VDC
Number of MPP Trackers/Max. Input Current
2/2x10A
2/2x13A
2/2×18.6A
GRID OUTOUT (AC)
Nominal Output Voltage
202/208/220/230/240 VAC
202/208/220/230/240 VAC
230 VAC (P-N)/
400 VAC (P-P)
Output Voltage Range
184-264.5 VAC*
184-264.5 VAC*
184-264.5 VAC* per phase
Nominal Output Current
21A
23.9A
14.5A per phase
AC INPUT
AC Start-up Voltage/Auto Restart Voltage
120-140 VAC/180 VAC
120-140 VAC/180 VAC
120-140 VAC per phase/
180 VAC per phase
Acceptable Input Voltage Range
170-280 VAC
170-280 VAC
170-280 VAC per phase
Max. AC Input Current
30A
30A
40A
BATTERY MODE OUTPUT (AC)
Nominal Output Voltage
202/208/220/230/240 VAC
202/208/220/230/240 VAC
230 VAC (P-N)/
400 VAC(P-P)
Efficiency (DC to AC)
93%
93%
91%
BATTERY& CHARGER
Battery DC Voltage
48V
Max. Charging Current
Default 60A
Default 60A, 10A-200A (Adjustable)
GENERAL
PHYSICAL
Dimension, D x W x H (mm)
204.2 x 460x 600
110*450*445
167.5 x 500 x 622
Net weight (kgs)
29
16
45
INTERFACE
Communication Port
RS-232/USB and CAN Interface
ENVIRONMENT
Humidity
0 ~90%RH
Operating Temperature
-10 to 55 ° C
0 to 40°C
-10 to 55 °C
Altitude
0-1000 m**
Packing & Delivery
FAQ
Are you trading company or manufacturer?
We are a professional manufacturer in China.
Where is the factory of Ruitong?
Zhengzhou City,Henan Province, China
What can I get to be Retonpower agent:
*More technical training, support and more free spare parts. *Special price support for Retonpower agent. *Advertising & publicity expenses share for Retonpower brand. *Annual bonus, based on your annual sales amount. *Fast good delivery as we have regular products in stock.
What can you buy from us?
Hybrid inverter, off grid solar inverter, solar panel,lithium iron battery ,storage solar system and electrical equipment.
